Description
● VF45 Patch Cord:
All VF45 patch cords are constructed with the innovative 3M "GGP" high-strength coated optical fiber, providing enhanced durability under tight bend radius conditions. VF-45 Fiber Optic Patch Cord is designed by 3M and features plug and jack design without the need to adapters. VF-45 plug is inserted into the socket (jack) at a 45-degree angle, pressing a pair of fibers into V-grooves inside the socket. The design of VF-45 Connector eliminates the need for expensive ferrules thus reduce connector costs.
● Features:
►VF-45 Connector is half the size of SC Connector
►Minimum space required when mounted in telecom enclosure or other racks
►VF-45 Optical Connector works on standard 62.5µm or 50µm multimode fiber
►Tested to TIA and IEC performance specifications
►RJ-45 style latch for ease of use and familiarity
►RoHS compliant for all VF-45 connector material
● Application:
►Interconnect socket (field terminated)
►Wall outlets and faceplates
►Termination and cleaning kits
►Test equipment
● Specification:
|
Parameters |
Standard Fiber Cable Assemblies |
|
|
Fiber Type |
SM(G.652/G.657A) |
MM(OM1/OM2/OM3/OM4/OM5) |
|
Jacket Materials |
LSZH/OFNR/PVC |
|
|
Connector Type |
SC/LC/ST/LC/MU/DIN/SMA/MTRJ/MPO/E2000 |
|
|
Ferrule Materials |
Ceramic |
|
|
Testing Wavelengths |
1310±30/1550±30nm |
850±30/1300±30nm |
|
Insertion Losss(dB) |
≤ 0.25dB (PC/UPC/APC) |
≤ 0.3dB (PC/UPC) |
|
Return Loss(dB) |
≥50dB(PC/UPC); ≥60dB(APC) |
≥40dB(PC/UPC) |
|
Exchangeability |
≤ 0.2dB |
|
|
Cable Assemblies |
Pigtail/Simplex/Duplex/Fan-out Patchcord |
|
|
Operating Temperature (° C) |
-10~ + 70 |
|
|
Storage Temperature (° C) |
-40 ~ +85 |
|
