Description
v Applications
1. Fiber Optic Networks
2. Telecommunications
3. Data Center Infrastructure
4. Fiber to the X (FTTX)
5. Surveillance Systems
6. Testing / Measurement Instruments
7. Community Antenna Television Systems (CATV)
8. Local Area Networks (LAN) & Wide Area Networks (WAN)
v Features
1. Factory products with a competitive price
2. OEM/ODM production and fast delivery
3. Low insertion loss and High reflection loss
4. Good exchangeability and durability
5. Standards: IEC, Telcordia GR-326-CORE
6. Customized cable connectors, colors, lengths and materials are available as required
v Specifications
|
Connector Type |
LC, SC, FC, ST, E2000, MTRJ, MU, DIN... (Customized) |
|
Fiber Type |
SM (G652, G657), MM (OM1, OM2, OM3, OM4, OM5) |
|
Polish Type |
PC, UPC and APC |
|
Cable Diameter |
0.9mm, 2.0mm, 3.0mm...(Customized) |
|
Outer Jacket Materials |
PVC, LSZH, OFNR, OFNP, Armored (Customized) |
|
Cable Assemblies |
Pigtail/Simplex/Duplex/Fan-out Patchcord (Customized) |
|
Insertion Loss |
≤ 0.3dB |
|
Return Loss |
PC≥40dB, UPC≥50dB, APC≥60dB |
|
Testing Wavelengths |
1310±30/1550±30nm (SM), 850±30/1300±30nm (MM) |
|
Repeatability |
≤ 0.1dB |
|
Durability |
|
|
Exchangeability |
≤ 0.2dB |
|
Operating Temperature |
-40℃~70℃ |
|
Storage Temperature |
-40℃~80℃ |
